RunCam Nano 2 1/3" 700TVL 1.8mm FOV 170 Degree CMOS FPV Camera for FPV RC Drone
| Part No.: | Nano2-1.8mm |
| Manufacturer: | Runcam |
Send to a friend
Features
RunCam Nano 2 1/3" 700TVL 1.8mm FOV 170 Degree CMOS FPV Camera for FPV RC Drone
Product Details
Brand name: Runcam
Model: Nano 2
Image Sensor: 1/3" CMOS
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 155° 1.8mm (M8) FOV 170°
Signal System: NTSC / PAL
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Auto Gain Control (AGC): Auto
Min. Illumination: 0.01Lux@1.2F
D-WDR: Auto
Day/Night: Color
Power: DC 3-5.5V
Current : 110mA@5V 120mA@3.3V
Housing Material: ABS
Net Weight: 3.2g
Dimensions: L14mm*W14mm*H16mm
Model: Nano 2
Image Sensor: 1/3" CMOS
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 155° 1.8mm (M8) FOV 170°
Signal System: NTSC / PAL
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Auto Gain Control (AGC): Auto
Min. Illumination: 0.01Lux@1.2F
D-WDR: Auto
Day/Night: Color
Power: DC 3-5.5V
Current : 110mA@5V 120mA@3.3V
Housing Material: ABS
Net Weight: 3.2g
Dimensions: L14mm*W14mm*H16mm
Item Packing
Camera x 1
1419 ABS bracket x 1
Set of screws x 1
1419 ABS bracket x 1
Set of screws x 1
Detailed Images
