FrSky R9 MM-OTA ACCESS 16CH 900MHz Long Range RC Mini Receiver S.Port RSSI Output

FrSky R9 MM-OTA ACCESS 16CH 900MHz Long Range RC Mini Receiver S.Port RSSI Output
Part No.: R9MM-OTA
Manufacturer: Frsky

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

The 900MHz R9 MM-OTA receiver implements the ACCESS protocol and brings the user improved performance and features. The R9 MM-OTA supports wireless firmware updates over the air making binding to receivers even easier. As well as the convenience of checking the current receiver firmware version. The R9 MM’s compact form factor design is also carried over to the OTA version, and the R9 MM-OTA supports inverted S.Port as well.

915MHz (Non-LBT Version)/ 868MHz (LBT Version)
Mini size and super lightweight
Supports OTA firmware update
Supports firmware version check
S.Port enabled and support telemetry data transmission
(Support F.Port, download firmware to support the function)
Inverted S.Port enabled
Low latency and high precision
With RSSI output in SBUS
Battery voltage detection supported
Detachable Ipex connector antenna

Product Details

Dimension: 16*10*2.8mm (L×W×H)
Weight: 0.7g (without antenna)
Number of Channels:
Non-LBT Version: 4/16CH (Telemetry)
LBT Version: 4/16CH (Telemetry) / 4/16CH (No Telemetry)
Operating Voltage Range: DC 3.5V – 10V
Operating Current: 100mA@5V
Operating Range: Up to 10km or above
Compatibility: R9M Lite/R9M/R9M 2019 with ACCST firmware
 R9M Lite/R9M Lite Pro/R9M 2019 with ACCESS firmware

Item Packing

FrSky R9 MM-OTA ACCESS 16CH 900MHz Long Range RC Mini Receiver x 1
