Hobbywing EZRUN MINI28 30A Sensored Brushless ESC Small Size Support Bluetooth Settings For 1/28 GL Racing/Drift Car
| Part No.: | EZRUN-MINI28 |
| Manufacturer: | Hobbywing |
Send to a friend
Features
Small size, light weight
High power, strong power
Abundance of parameter items
Two profiles
Built-in adjustable BEC
OTA support
The powerful software and hardware are built into the Mini28 ESC.
It features new programmable parameters and is optimized for 1/28 competitions.
High power,
low temperature
The fully-alloy heat sink ensures that the ESC can dissipate heat and operates at a healthy temperature range while the maximum output current can be up to 30A
High power, strong power
Abundance of parameter items
Two profiles
Built-in adjustable BEC
OTA support
The powerful software and hardware are built into the Mini28 ESC.
It features new programmable parameters and is optimized for 1/28 competitions.
High power,
low temperature
The fully-alloy heat sink ensures that the ESC can dissipate heat and operates at a healthy temperature range while the maximum output current can be up to 30A
Product Details
Type
- Scale：1/28th
- Brushed/Brushless：BL
- Sensored/Sensorless：SD
- Waterproof：No
Specifications
- Cont./Peak Current：30A/80A
- Input Voltage：2S Lipo
- BEC Output：6V/7.4V @Max 3.5A
Wires & Connectors
- Input Wires：Black-20AWG-55mm*1 Red-20AWG-55mm*1
- Output Wires：Black-22AWG-80mm*3
(Note: All the wire length above is the original length not the length you see from the outside.)
ESC Programing via
- SET Button on ESC：Not Supported
- LED Program Box：Not Supported
- LCD G2 Program Box：Supported
- OTA Programmer：Supported
- Program Port：Throttle Wire
Firmware Upgrade：Supported
Size & Weight
- Size：22.7x14.2x11.8mm
- Weight：5g (without wires)
Applications
- Motors：1626 Size Motors
- Vehicles：1/28th&1/27th
- Scale：1/28th
- Brushed/Brushless：BL
- Sensored/Sensorless：SD
- Waterproof：No
Specifications
- Cont./Peak Current：30A/80A
- Input Voltage：2S Lipo
- BEC Output：6V/7.4V @Max 3.5A
Wires & Connectors
- Input Wires：Black-20AWG-55mm*1 Red-20AWG-55mm*1
- Output Wires：Black-22AWG-80mm*3
(Note: All the wire length above is the original length not the length you see from the outside.)
ESC Programing via
- SET Button on ESC：Not Supported
- LED Program Box：Not Supported
- LCD G2 Program Box：Supported
- OTA Programmer：Supported
- Program Port：Throttle Wire
Firmware Upgrade：Supported
Size & Weight
- Size：22.7x14.2x11.8mm
- Weight：5g (without wires)
Applications
- Motors：1626 Size Motors
- Vehicles：1/28th&1/27th
Item Packing
EZRUN MINI28 30A Sensored Brushless ESC x 1
Detailed Images
