RunCam Mini FPV DVR Lossless video output for VTX for Mini FPV Racing Drone

RunCam Mini FPV DVR Lossless video output for VTX for Mini FPV Racing Drone
Part No.: RC-DVR
Manufacturer: Runcam

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

* Designed for Mini FPV Racing Drone! ( 25*25mm @ 20*20mm M2 holes)
* Lossless video output for VTX!  (Since it has been loaded to the DVR, it needs to synchronize the video amplification output)
* Black technology! Can record high-frequency vibration motor audio without access to MIC!

Product Details

Brand name: Runcam
Item name: Mini FPV DVR Module
Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g

Remote Control Version
Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording.

Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)

Item Packing

Runcam Mini FPV DVR Module x 1

Detailed Images
