LX Servo and Other Servo > Product details

kingmax KM0940MD--13g 4.6kg.cm digital aluminium gears mini servo for mini glider or small Rc car

kingmax KM0940MD--13g 4.6kg.cm digital aluminium gears mini servo for mini glider or small Rc car
Part No.: KM-0940MD
Manufacturer: KINGMAX

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

Item: KM0940MD
Gear: Full metal
Spline: Exclusive
Motor: DC motor
Bearing: No
Dead band: 4μs default
Waterproof: No
Operating Voltage: DC5.0~8.4V
Working frequence: 1520μs/330hz-- Programmable digital MINI servo

-- High-precision metal gears for smooth action and durability
-- High quality brushed motor

Product Details

Dead band: 4μs default
Operating Speed(5.0V):0.14sec/60degrees
Operating Speed(6.0V):0.12sec/60degrees
Operating Speed(7.4V):0.11sec/60degrees
Operating Speed(8.4V):0.10sec/60degrees
Stall torque(7.4V):4.6kg.cm(63.89oz/in)
Maximum working torque(7.4V):2.8kg.cm(38.89oz/in)
Rated working torque(5.0V):0.5kg.cm(6.94oz/in)
Rated working torque(6.0V):0.8kg.cm(11.11oz/in)
Rated working torque(7.4V):1.1kg.cm(15.27oz/in)
Rated working torque(8.4V):1.3kg.cm(18.05oz/in)
Dimensions:23.8*11.5*21.6mm/0.92X0.45X0.84in
Weight:13g(0.45oz)
Connector Wire Length:JR300mm(11.7in)



When the PWM signal is between 1.0 and 2.0, the working angle is 90°
When the PWM signal is 0.5 to 2.5, the working angle is 180°

Item Packing

aluminium gears mini servo x 1

Detailed Images
