HEX Herelink V1.1 5.5in screen 2.4GHz 20KM Long Range HD Digital Video telemetry Transmission System HDMI 720P 1080P 30/60fps HX4-06212

HEX Herelink V1.1 5.5in screen 2.4GHz 20KM Long Range HD Digital Video telemetry Transmission System HDMI 720P 1080P 30/60fps HX4-06212
Part No.: HEX-Herelink
Manufacturer: HEX

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

*All in one: Telemetry, Video, and control
*Up to 20KM in FCC mode and 12KM in CE mode
*2.4Ghz frequency
*UART Telemetry
*RC Protocol: SBUS, iBUS, ETC.
*Mavlink compatible
*Touch screen
*HDMI input x2 for 1080P video transmission @ 60fps
*APP QGround control, and API for development.
*WIFI, Bluetooth and USB to connect with other devices

Product Details

Hardware specification
- Processor:SoC – Pinecone S1,AP: 4 x large core, Cortex A53, 2.2GHz,4 x small core, Cortex A53, 1.4GHz,GPU: 4 core, Mali-T860,SDR: A7 + DSP
- Storage:Air Unit LPDDR3 1GB,Controller LPDDR3 2GB
- Air Unit/Controller:EMMC 4GB
- Transmission Range:FCC 20km CE/SRRC 12km
- Latency:Min 110ms
- Resolution:720p@30fps, 1080p@30/60fps
- Frequency Band:2.4GHz ISM
- Receive sensitivity:-99dBm@20MHz BW
- Interference recovery:< 1s

Air Unit
- Housing:Aluminum
- Weight:95g (w. antennas)
- Dimension:78.5x30x15mm (w/o antennas)
- Signal Bandwidth:20MHz/10MHz
- Power Consumption:< 4W
- HDMI 1:Micro HDMI, for video input (preferred)
- HDMI 2:Micro HDMI, for video input
- Power:Recommended supply voltage ~7V, minimum 6V, maximum,12V and avoid sharing BEC with servos
- Micro USB:For debug or upgrade, support OTG
- Pair/Reset:For pairing and reset
- LED 1, 2:To indicate pairing status and transmission status
- UART:3.3V / 5V UART
- S.bus:Two 3.3V RC output
- ANT 1, 2:MMCX, for signal transmission and communication

Controller
- Housing:Plastic
- Weight:516g (w. antennas)
- Dimension:217x106.5x31mm (w/o antennas, joysticks )
- Screen:5.46 inch, 1080P, 16 million colors, capacitive touch screen
- Audio:1 x built-in speaker, 2 x built-in microphone
- Remote control:2 x joystick, 1 x wheel, 6 x button (w. blacklight), 1 x upper right button
- Communication:WIFI/GPS 2.4GHz on the controller side
- LED:2 x tricolor LED (left, right)
- Interface:1 x MicroUSB, 1 x Micro SD card slot (extendable to max. 64GB)
- Antenna:1 x detachable directional (5dBi), 1 x detachable omni-directional (2dBi), built-in WIFI antenna, built-in GPS antenna, external GPS antenna interface
- Power:4950mAh built-in Lipo Battery
- Charging:Support micro USB 5V 2A charging
- Power consumption:< 4W average (With transmission on, medium screen brightness, WIFI off, GPS off)

Item Packing

Accessories
HereLink Airunit *1
HereLink Controller *1
Omnidirectional antenna *1
Directional antenna *1
Airunit antenna *2
Joy-stick *2
HDMI cable *1
Power cable *1
Telemetry cable *1
S.bus cable *1
USB cable *1
Back board *1
M1.6x16mm(Fan screw)*5
M1.6(Fan Nut)*5
Washer(Fan washer)*5
O-ring(Fan O-ring)*20
M1.6x3mm(Airunit case screw)*5
M3x10mm(Back board mounting screw)*3
M3 Nut(Back board mounting nut)*3
Fan*1(available in Herelink1.1)
