Radiomaster MT12 Surface Radio Controller 2.4G 4in1 Multiprotocol With R85C Receiver for RC Car Boat
| Part No.: | MT12-4IN1-R85C |
| Manufacturer: | RadioMaster |
Send to a friend
Features
The RadioMaster MT12 is a pioneering open-source surface radio, and the first surface radio officially supported by EdgeTX, ExpressLRS, and the Multi-module project. Boasting 10 physical inputs and the capability to handle either 16 or 32 channels*, the MT12 is primed for a wide array of surface models, from cars and trucks to boats and beyond. Featuring extensive customizability and a versatile operating system, the MT12 stands out as a highly configurable surface radio, prepared to excel in virtually any scenario.
* Available with built-in 4in1 MPM RF modules
* Featuring a powerful STM32F407VGT6 with 1MB Flash
* Preinstalled EdgeTX firmware
* QC3.0 fast charging supporting 2.0A MAX
* Compact design with excellent ergonomics
* Oversized battery compartment - 2 x 18650 cells or a 2s 7.4v * 5000mah battery pack (Batteries not included)
* Standard Nano module compartment
* RadioMaster standardized button layout
* Rotatable antenna
* Customizable base switches or 4 way joystick included
Product Details
Item: MT12 Surface Radio
Physical dimensions: 177.8*118.4*207.8mm
Weight: 480 grams
Operating frequency: 2.400GHz-2.480GHz
Internal RF Options: 4-in-1 multi-protocol
Supported protocols: Module dependent
Operational current: 160mA for 4in1 / 320mA for ELRS
Operational voltage: DC 6.6-8.4V
Operating system: EdgeTX
Control channels: 16 as standard, ability for expansion 32 Channels (4in1 only)
Display: 128*64 Monochrome LCD
Battery: 2 x 18650 cells or a 2s 7.4v 5000mah battery pack (Batteries not included)
Charging: Built in USB-C Charging
Firmware Upgrade method: Via USB or SD card
Wheel and Trigger sensor: Hall-effect
Module bay: Nano size (RadioMaster Ranger Nano Module / RadioMaster RM 4in1 module / TBS Crossfire Nano module)
*32 channels requires a 4in1 radio and additional 4in1 RF module along with compatible receivers
Specification R85C (Included with 4in1 version)
Item: R85C Receiver
Power supply: DC 4.5 - 8.4V
Frequency range: 2400-2483.5Mhz
Support protocol: D8/D16/SFHSS
Output channel: 5CH PWM
Antenna type: high-sensitivity 2.4G antenna
Telemetry power: 100mw / 20dbm
Weight: 5.7 grams
Dimensions: 31.0*18.5*13.0 mm
Item Packing
1 * R85C Receiver
1 * Dual Switch Expansion module
1 * 4 Way Joystick Expansion module
1 * Nano Adapter
1 * USB-C Cable
1 * Leather Lanyard
1 * Custom RadioMaster signature carry case
1 * 18650 Battery Tray
1 * Screen Protector
1 * Stickers
1 * Manual
