EAI YDLIDAR G4 Lidar 16Meter ranging sensor for Navigation and obstacle avoidance and Ground wall screen interaction
| Part No.: | LIDAR-G4 |
| Manufacturer: | Feixiang |
Send to a friend
Features
YDLIDAR G4 is a 360-degree two-dimensional rangefinder (hereinafter referred to as G4)
developed by YDLIDAR team. Based on the principle of triangulation, it is equipped with related
optics, electricity, and algorithm design to achieve high-frequency and high-precision distance
measurement. The mechanical structure rotates 360 degrees to continuously output the angle
information as well as the point cloud data of the scanning environment while ranging.
--360 degree scanning distance measurement
--Small distance error, stable performance and high accuracy
--Ranging distance is not less than 16m
--Strong resistance to ambient light interference
--Industrial brushless motor
--Laser power meets Class I laser safety standards
--5-12Hz adaptive scanning frequency (support customization)
--Ranging frequency 9kHz (Max.) (support customization)
Product Details
- Robot navigation and obstacle avoidance
- Robot ROS teaching and research
- Regional security
- Environmental scanning and 3D reconstruction
- Commercial robot /Robot vacuum cleaner
Item Packing
Detailed Images
