Benewake TF03-180 Lidar IP67 180m Long-range Distance Laser Sensor Support UART Communication Interface
| Part No.: | TF03-180 |
| Manufacturer: | Feixiang |
Send to a friend
Features
TF03 is a industrial high-speed LiDAR, It contains two versions with 100m and 180m. TF03 includes compensation algorithms for outdoor glare and other interference, so it works normally under strong light environment and rain, fog and snow conditions. Different built-in operating modes let customers change parameters and configuration to meet their need. The product is applicable to the terrain following of drones, the collision avoidance of cars, intelligent transportation and industrial safety warning.
Product Details
Product performance
- Operating range：0.1m-180m@90% reflectivity；0.1m-70m@10% reflectivity；0.1m-130m@90% reflectivity&100Klux；0.1m-50m@10% reflectivity&100Klux
- Accuracy：±10cm (within 10m), 1% (10m and further)
- Distance resolution：1cm
- Frame rate：1Hz~1000Hz adjustable (default 100Hz)
- Ambient light immunity：100Klux
- Operation temperature：-25~60℃
- Enclose rating：IP67
Optical parameters
- Light source：LD
- Central wavelength：905nm
- Photobiological safety：CLASS1(EN60825)
- FOV：0.5°
Electrical parameters
- Supply voltage：5V
- Average current：≤180mA
- Power consumption：≤0.9W
- Communication level：LVTTL(3.3V)
- Communication interface：UART/CAN/IO
- Operating range：0.1m-180m@90% reflectivity；0.1m-70m@10% reflectivity；0.1m-130m@90% reflectivity&100Klux；0.1m-50m@10% reflectivity&100Klux
- Accuracy：±10cm (within 10m), 1% (10m and further)
- Distance resolution：1cm
- Frame rate：1Hz~1000Hz adjustable (default 100Hz)
- Ambient light immunity：100Klux
- Operation temperature：-25~60℃
- Enclose rating：IP67
Optical parameters
- Light source：LD
- Central wavelength：905nm
- Photobiological safety：CLASS1(EN60825)
- FOV：0.5°
Electrical parameters
- Supply voltage：5V
- Average current：≤180mA
- Power consumption：≤0.9W
- Communication level：LVTTL(3.3V)
- Communication interface：UART/CAN/IO
Item Packing
Benewake IP67 180m Distance Lidar x 1
