HolyBro DroneCAN H-RTK F9P Rover High-Precision GNSS Positioning System for OpenSource Pixhawk Flight Controller
| Part No.: | HL-12034 |
| Manufacturer: | Holybro |
Send to a friend
Features
DroneCAN F9P Rover
The Rover model has a flatter profile and stronger water resistance. It uses a dual band patch antenna and comes with an integrated cable to connect to the CAN bus. It excels in spaces where there are few obstructions.
The Rover model has a flatter profile and stronger water resistance. It uses a dual band patch antenna and comes with an integrated cable to connect to the CAN bus. It excels in spaces where there are few obstructions.
Product Details
Intended Application：Rover (aircraft) only
GNSS Receiver：U-blox ZED-F9P high precision GNSS module
Antenna：Ceramic Patch Antenna with 20dB LNA
Processor：STM32G473
Magnetometer：BMM150
GNSS：BeiDou, Galileo, GLONASS, GPS / QZSS
GNSS Band：B1I, B2I, E1B/C, E5b, L1C/A, L1OF, L2C, L2OF
Positioning accuracy：3D FIX: 1.5 m / RTK: 0.01 m
Communication Protocol：DroneCAN 1Mbit/s
Antennas Peak Gain (MAX)：L1: 4.0dBi，L2:1.0 dBi
Time-TO-First Fix：Cold start: ≤29s，Hot start: ≤1s
Navigation Update Rate：RAW: 20Hz Max，RTK: 8Hz Max
Cable Length：27cm or 42cm（Optional）
Antenna Connection Type：N/A
Working voltage：4.75V~5.25V
Current Consumption：~250mA
Dimensions：Diameter: 80mm Height: 20mm
Weight：123g
Operating Temperature：-20℃ to 85℃
Item Packing
•1x DroneCAN F9P Rover
•1x Fixed Carbon Fiber GPS mount
•1x Fixed Carbon Fiber GPS mount
Detailed Images
