Hobbywing X11 MAX Motor Power System 11122 18S 60KV 48175 Propeller CW for Multirotor Agriculture Drone
| Part No.: | X11-MAX-CW |
| Manufacturer: | Hobbywing |
Send to a friend
Features
Hobbywing X11 MAX Motor Power System 11122 18S 60KV 48175 Propeller CW for Multirotor Agriculture Drone
Product Details
Product Name: XRotor X11-MAX
Specifications
Max. Thrust: 44kg/Axis (70V, Sea Level)
Recommended Takeoff Weight: 20-22kg/Axis (46V, Sea Level)
Recommended LiPo Battery: 18S（LiPo）
Operating Temperature: -20~50℃
Combo Weight: 2800g
Waterproof Rating: IPX6
Motor
Steering: CW
KV Rating: 60 rpm/V
Stator Size: 111*22mm
Powertrain Arm Tube Outer Diameter: 50mm
Bearing
ESC
Recommended LiPo Battery: 18S(LiPo)
PWM Input Signal Level: 3.3V/5V
Throttle Signal Frequency: 50-500Hz
Operating Pulse Width: 1050-1950-us(Fixed or cannot be Programmed)
Max. Input Voltage: 78.3V
Max. Input Current (Short duration): 150A(w/ Good Heat Dissipation)
BEC: No
Propeller
Diameter×Pitch: 48*17.5
Item Packing
Hobbywing X11 MAX Motor Power System CW x 1set
