5.8GHz Triple Feed Patch Array 14dBi Gain SMA RP-SMA Male Port Image Transmitter Flat Panel Antenna for FPV Drone Airplane
| Part No.: | PA-14DBI |
| Manufacturer: | Feixiang |
Send to a friend
Features
1PCS 5.8GHz Triple Feed Patch Array 14dBi Gain SMA RP-SMA Male Port Image Transmitter Flat Panel Antenna for FPV Drone Airplane
Product Details
- Item name: triple feed patch antenna
- Center frequency: simulated:5.8GHz; measured:5.8GHz±100MHz
- Bandwidth: simulated:660MHz(5.47-6.13GHz); measured:950MHz±100MHz[Feed network losses increase bandwidth]
- Matching: simulated:S11＜-30dB,VSWR＜1.065; measured:S11＜-20dB,VSWR＜1.22[At center frequency]
- Axial ratio: simulated:1.05(0.38dB); measured:1.10(0.83dB)[Averaged over beam width]
- Antenna gain: simulated:14.4dBi; measured:14.0dBi
- Half power beam width: simulated:30°; measured:30°[horizontal and vertical]
- Radiation efficiency: simulated:75%; measured:74%
- Port:SMA male/RP-SMA male（optional）
- Diameter:150mm
- Center frequency: simulated:5.8GHz; measured:5.8GHz±100MHz
- Bandwidth: simulated:660MHz(5.47-6.13GHz); measured:950MHz±100MHz[Feed network losses increase bandwidth]
- Matching: simulated:S11＜-30dB,VSWR＜1.065; measured:S11＜-20dB,VSWR＜1.22[At center frequency]
- Axial ratio: simulated:1.05(0.38dB); measured:1.10(0.83dB)[Averaged over beam width]
- Antenna gain: simulated:14.4dBi; measured:14.0dBi
- Half power beam width: simulated:30°; measured:30°[horizontal and vertical]
- Radiation efficiency: simulated:75%; measured:74%
- Port:SMA male/RP-SMA male（optional）
- Diameter:150mm
Item Packing
14dBi Antenna x1
Detailed Images
