Caddx Vista HD Digital System VTX FOV Camera 1080P Recording for FPV Racing Drone

Caddx Vista HD Digital System VTX FOV Camera 1080P Recording for FPV Racing Drone
Part No.: CD-VISTA
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

Stable and clear HD video.
Single antenna,max range is up to 4km.
Allow up to 8 drones to fly simultaneously.
Embedded remote controller receiver.
28ms low latency,high definition digital image transmission.

Description:
The Vista HD System is designed for small drones and whoop drones. It can work with FPV Camera, FPV Goggles and FPV Remote Controller. Compatible with two sizes,20x20mm/25.5x25.5mm, compatible with toothpick drones.

Product Details

Brand Name: Caddx.us
Item Name: Vista Kit
Operating Frequency: 5.725-5.850GHz
Transmitter Power(EIRP): FCC/SRRC/MIC: Less than 30dBm, CE: Less than 14dBm
Min. Latency (end-to-end): Low Latency Mode(720p 120fps): 21-28ms, High Quality Mode(720p 60fps): 30-40ms
Max. Transmission Distance: FCC/SRRC: 4km, CE: 0.7km
I/O Interface: USB-C,IPEX,3-in-1 Port,card slot
Supported Flight Control System: F3,F4,F7
Operating Temperature Range: 32° to 104° F (0℃ ~40℃)
Input Power: 7.4-26.4V
Camera Specifications:
Sensor: 1/3.2inch CMOS
Effective Pixels: 4M
Lens: 2.1mm,f/2.1
Shutter: Rolling shutter
ISO: 100-25600
FOV: 150° (D);122° (H);93° (V)
Weight:
Vista Kit(camera included): 29g
Antenna: 3.5g
Dimensions:
Vista Kit: 30x29x13mm
Camera: 27.4x21.1x20.1mm
Coaxial Cable:80mm
colour: silver
Material: ABS plastic

Item Packing

Caddx Vista Digital HD System x 1

Detailed Images
