DMKR LS-5804 3 inch FPV Mini Handheld LCD Monitor 480*320 IPS Screen With DVR Built-in Battery for DJI goggles FPV RC Drone
Part No.: | LS-5804 |
Manufacturer: | Feixiang |
Send to a friend
Features
● Small size and light weight;
● Low power consumption, Working current 360~400mA;
● RaceBand 40 channel, Auto-Searching;
● 3.0 Inch 480*320 dot high brightness LCD screen;
● Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
● Built-in 3.7V/800mAh high-capacity Li-ion polymer Battery;
● Universal USB charging interface;
● Real-time video return, Very low time-delay;
● Bilingual menu in support of Chinese and English;
● Support external video signal input;
● Support AV signal output (Connect external DVR);
● It can be used as a receiver for "DJI" and other video glasses. With interest screen function;
● Low power consumption, Working current 360~400mA;
● RaceBand 40 channel, Auto-Searching;
● 3.0 Inch 480*320 dot high brightness LCD screen;
● Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
● Built-in 3.7V/800mAh high-capacity Li-ion polymer Battery;
● Universal USB charging interface;
● Real-time video return, Very low time-delay;
● Bilingual menu in support of Chinese and English;
● Support external video signal input;
● Support AV signal output (Connect external DVR);
● It can be used as a receiver for "DJI" and other video glasses. With interest screen function;
Product Details
Model: LS-5804
Name: Mini FPV MONITOF
LCD Screen
- Screen : 3.0 Inch IPS LCD
- Resolution: 480*320
- Display Ratio: 16:9
- View Angle: 360 ° without dead angle
- Brightness: 500cd/m² with high brightness backlight LED
Video delay: Video time-delay less than 20ms
Interface
- Antenna: RP-SMA male
- USB: To charge the battery
- AV Jack: External video signals input or internals AV signal output
Languages: English and Chinese
Power Supply
- Power adapter: DC5V/1A (USB interface)
- Battery: 3.7V/800mAh,Each full charge revive around 2hr working time
- Power Consumption: *The device operating current of 360~400mA at 3.7~4.2V; *Built-in battery maximum charge current of 800mA;
Dimensions and weight
- Body size:8.4cm * 5.3cm * 1.4cm
- Packing size: 12cm * 11cm * 25cm
- Body weight: 65g (not included antennas)
- Package weight: 167g
Name: Mini FPV MONITOF
LCD Screen
- Screen : 3.0 Inch IPS LCD
- Resolution: 480*320
- Display Ratio: 16:9
- View Angle: 360 ° without dead angle
- Brightness: 500cd/m² with high brightness backlight LED
Video delay: Video time-delay less than 20ms
Interface
- Antenna: RP-SMA male
- USB: To charge the battery
- AV Jack: External video signals input or internals AV signal output
Languages: English and Chinese
Power Supply
- Power adapter: DC5V/1A (USB interface)
- Battery: 3.7V/800mAh,Each full charge revive around 2hr working time
- Power Consumption: *The device operating current of 360~400mA at 3.7~4.2V; *Built-in battery maximum charge current of 800mA;
Dimensions and weight
- Body size:8.4cm * 5.3cm * 1.4cm
- Packing size: 12cm * 11cm * 25cm
- Body weight: 65g (not included antennas)
- Package weight: 167g
Item Packing
DMKR LS-5804 LCD Monitor x 1set
