MATEK CAN-G474 Board with 5Mbit/s CAN Transceiver and STM32G474 MCU AP_PERIPH CAN NODE for RC FPV Drone
| Part No.: | MA-CAN-G474 |
| Manufacturer: | Matek |
Send to a friend
Features
*CAN-G474 is an Adapter Node based on ArudPilot AP_Periph firmware.
*With 5Mbit/s CAN transceiver and STM32G474 MCU, CAN-G474 is capable of CANFD.
*With this board, you can easily utilize the ArduPilot driver library to convert ArduPilot supported GNSS, Compass, Barometer, Airspeed sensor, Rangefinder, Proximity sensor, Electronic Fuel Injectors and GPIO based (PWM, LED notify) peripherals to DroneCAN bus peripherals.
*With 5Mbit/s CAN transceiver and STM32G474 MCU, CAN-G474 is capable of CANFD.
*With this board, you can easily utilize the ArduPilot driver library to convert ArduPilot supported GNSS, Compass, Barometer, Airspeed sensor, Rangefinder, Proximity sensor, Electronic Fuel Injectors and GPIO based (PWM, LED notify) peripherals to DroneCAN bus peripherals.
Product Details
* MCU: STM32G474CE, 512KB Flash
* CAN transceiver data rates up to 5Mbit/s
* 2x CAN bus
* 4x UARTs
* for peripheral GNSS, Rangefinder, Proximity, EFI, RC input(receiver)
* support GNSS, Compass, Barometer sensors over MSP protocol. MSP is enable on TX3 by default.
* 2x I2C bus
* for peripheral I2C Airspeed sensor, Barometer, Compass
* 1x SPI
* for peripheral RM3100
* SPI pads for RM3100 are on bottom side, with “CS, MOSI, MISO, SCK” silkprint
* 11x PWM outputs
* for Servos and ESC, all PWMs support DMA/DShot
* PWM1-10 on DuPont 2.54mm holes
* PWM11 pad is on bottom side, with “11” silkprint
* ST debug, SWC & SWD(on bottom side)
* UART1(TX1,RX1) support firmware update in DFU mode
LED
* Blue, Fast blinking, Booting
* Blue, Slow blinking, communicating with flight controller
* Red, 3.3V indicator
* Input voltage range: 4.5~5.5V @5V pad/pin
* Power consumption: 62mA
* Operating Temperatures: -30~85 °C
Physical
*5x JST-GH-4P(SM04B-GHS-TB) for CAN1, CAN2, I2C1, UART1 and UART4
*1x JST-GH-6P(SM06B-GHS-TB) for UART3+I2C2
*18x DuPont 2.54mm holes
*Board Size: 36mm*36mm*6mm. 5.2g,
*Mounting: 30.5mm 4x Dia.3mm
* CAN transceiver data rates up to 5Mbit/s
* 2x CAN bus
* 4x UARTs
* for peripheral GNSS, Rangefinder, Proximity, EFI, RC input(receiver)
* support GNSS, Compass, Barometer sensors over MSP protocol. MSP is enable on TX3 by default.
* 2x I2C bus
* for peripheral I2C Airspeed sensor, Barometer, Compass
* 1x SPI
* for peripheral RM3100
* SPI pads for RM3100 are on bottom side, with “CS, MOSI, MISO, SCK” silkprint
* 11x PWM outputs
* for Servos and ESC, all PWMs support DMA/DShot
* PWM1-10 on DuPont 2.54mm holes
* PWM11 pad is on bottom side, with “11” silkprint
* ST debug, SWC & SWD(on bottom side)
* UART1(TX1,RX1) support firmware update in DFU mode
LED
* Blue, Fast blinking, Booting
* Blue, Slow blinking, communicating with flight controller
* Red, 3.3V indicator
* Input voltage range: 4.5~5.5V @5V pad/pin
* Power consumption: 62mA
* Operating Temperatures: -30~85 °C
Physical
*5x JST-GH-4P(SM04B-GHS-TB) for CAN1, CAN2, I2C1, UART1 and UART4
*1x JST-GH-6P(SM06B-GHS-TB) for UART3+I2C2
*18x DuPont 2.54mm holes
*Board Size: 36mm*36mm*6mm. 5.2g,
*Mounting: 30.5mm 4x Dia.3mm
Item Packing
1×MATEK CAN-G474 Board
