CUAV ISTRA24 20Dbi Miniature Drone Altimeter Obstacle Avoidance Radar Sensor 50M 50Hz

CUAV ISTRA24 20Dbi Miniature Drone Altimeter Obstacle Avoidance Radar Sensor 50M 50Hz
Part No.: CU-ISTRA24
Manufacturer: CUAV

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

(ISTRA24) has the PCBA size as little as 45*45mm and the weight of 6.5g, which is very convenient for being integrated to body of UAV body or under the arms of the machine. An original antenna design,the signal processing algorithm of super-high efficiency and the comprehensive real-time signal pro-cessing method of high sensitivity based on time domain, frequency domain and phase positions to greatly reduce the physical size of radar modules, making it convenient to integrate the radar model into the body of UAV and bringing in a brand new probability for UAV industry. lt is possible for this millimeter-wave altimeter radar to realize altitude measurement in the range of 0.2 ~ 50m (it is not suggested hovering for a long time under the altitude of 0.5m), which providing a remarkable convenient feature for hov-ering or flying upon a constant distance to ground by UAV.

Product Details

System Features
Transmitting frequency: 24.0~24.25GHz
Transmitting power (EIRP): 20dBm
System: Frequency Modulated Continuous Wave
Hardwareinterface: UART-TTL
Dimension:45*45*6mm (PCBA)
Weight: 6.5g
Working voltage: 4~5.5V Typical value: 5V (please make use of an independent power supplysystem to power up)
Working current:200~275mA Typical value:220mA@5V
Storage temperature:-40~85C
Working Temperature:-40~80C

Ranging Features
Altitude-fixing range: 0.2m ~50m
Update rate: 50Hz

Aerial Features
Degree of the transmitting antenna's tilt angle: 20°
Width of the receiving antenna's tilt angle: 31°
Width of the transmitting antenna's azimuthal angle: 31°
Width of the receiving antenna's azimuthal angle: 20°
Electrical level of the transmitting antenna's sidelobe -19dB
Electrical level of the receiving antenna's sidelobe -19dB

Item Packing

CUAV ISTRA24 Radar Sensor x1

Detailed Images
