FrSky R9 Slim+ OTA ACCESS 16CH 900MHz RC Receiver Support Wireless Upgrade Firmware Update
| Part No.: | R9slim+OTA |
| Manufacturer: | Frsky |
Send to a friend
Features
ACCESS Protocol and support OTA functions
Low latency and high precision
Support S.Port / F.Port (Configurable in OpenTX / FrOS menu)
With inverted SBUS and S.Port outputs
Battery voltage detection supported
Detachable Ipex1 connector antenna
Low latency and high precision
Support S.Port / F.Port (Configurable in OpenTX / FrOS menu)
With inverted SBUS and S.Port outputs
Battery voltage detection supported
Detachable Ipex1 connector antenna
Product Details
Dimension: 32*13.5*5mm (L × W ×H)
Weight: 4.3g (with antennas)
Numbers of channel
-Non-LBT Version: 6/16CH (Telemetry)
-LBT Version: 6/16CH (Telemetry) / 6/16CH (No Telemetry)
With RSSI Output : Analog 0~3.3V
Operating Voltage Range: DC 3.5V~12.6V (1~3s Li-Battery)
Operating Current: 100mA@5V
Operating Range: up to 10km or above
Compatibility: R9M 2019/R9M Lite/R9M lite Pro with ACCESS firmware
Weight: 4.3g (with antennas)
Numbers of channel
-Non-LBT Version: 6/16CH (Telemetry)
-LBT Version: 6/16CH (Telemetry) / 6/16CH (No Telemetry)
With RSSI Output : Analog 0~3.3V
Operating Voltage Range: DC 3.5V~12.6V (1~3s Li-Battery)
Operating Current: 100mA@5V
Operating Range: up to 10km or above
Compatibility: R9M 2019/R9M Lite/R9M lite Pro with ACCESS firmware
Item Packing
R9 Slim+ OTA Receiver x 1
Detailed Images
