HobbyWing EZRUN 70125SD 560KV Sensored Brushless Waterproof Motor For 1/5 Scale Car Off-road Trucks RC Car Parts

HobbyWing EZRUN 70125SD 560KV Sensored Brushless Waterproof Motor For 1/5 Scale Car Off-road Trucks RC Car Parts
Part No.: EZRUN-70125SD-560KV
Manufacturer: Hobbywing

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

* Fully sensored mode,High power
The EZRUN series of motors are known to be dynamic and dominant. They are built differently to meet the needs of various demands on the market. It has a strong output power with an excellent linearity at low speed and is operating on full-sensored mode.
* Applicable to All Weather & Track Conditions
The IP-67 waterproof system guarantees excellent waterproofing and dustproofing protection.The whole power system is able to drive on a variety of surfaces including muddy,sandy, icy, snowy and water without damaging the power unit.
* A perfect combo with the EzRun MAX4 HV ESC
The motor achieves perfect compatibility when used together with the EzRun MAX4 HV ESC.It provides ultra-large torque, precise handling performance,and brings a smooth and comfortable control experience to the users.
* Ultra-high efficiency effectively reduces the operating temperature of the motor
Hobbywing technology helps to solve the degradation caused by motor overheating.It ensures that the motor is always in good working conditions.

Product Details

Product Name:EZRUN 70125SD
Product Number:30402850
Type
- Scale: 1/5th
- Brushed/Brushless: BL
- Sensored/Sensorless: SD
- Pole Count: 4
Relevant Parameters
- KV Rating: 560KV
- LiPo Cells: 8-12S
- No-load Current(A): 3.6A
Size & Weight
- O.D.(mm): 70
- Length (mm): 125
- Shaft Diameter (mm): 8
- Weight (g): 1995g
- Front Bearing: D22*D8*T7
- Rear Bearing: D22*D8*T7
Other Parameters
- Applications: 1/5th Heavy-duty Off-road, Truck.

Item Packing

EZRUN 70125SD 560KV Motor x 1
