UltraPower UP7 AC200W DC400W 10A x 2 Dual Channel Balance Charger Discharger for Lipo LiHV Lilon LiFe RC Models Battery
| Part No.: | LC-UP7 |
| Manufacturer: | UltraPower |
Send to a friend
Features
AC / DC TWO Channels
Support AC or DC Input, meet different needs, output power is 200W in AC mode，400W in DC mode
2.4'' High-definition IPS colorful screen
all the data are visible under the sunshine , easy to get the information
Dual channel output, higher efficiency
Independent dual channel output, without interference by each other, single channel current up to 10.0A, support to charge 2pcs different type batteries simultaneously. Including Lipo, LIHV, Lilon, Life, Nimh, Nicd, Lead Acid.
Product Details
Input Voltage: AC 100-240V , DC 9.0-32.0V
Output Voltage: 0.1-30.0V
Charging Current: 0.1-10.0A x 2
Discharge Current
• CH1: 0.1-2.0A / 0.1-15.0A ( External discharge mode)
• CH2: 0.1-2.0A
Charge Powe
• DC Input: 2 x 200W
• AC Input: Max 200W (CH1 + CH2 = 200W)
• Support power distribution
Discharge Power
• CH1: 6W / 200W (External discharge mode)
• CH2 : 6W
Balance Current: Max.1000mA / cell
Support Battery Types:
• Lipo / LIHV / Life / Lilon (1-6S)
• NIMH / Nicd (1-16s)
• Lead Acid 2V-24V (1-12S)
LCD Screen type: 24'' 320X240 IPS LCD
Dimensions: 100 x 199 x 64mm
Weight: 450g
Output Voltage: 0.1-30.0V
Charging Current: 0.1-10.0A x 2
Discharge Current
• CH1: 0.1-2.0A / 0.1-15.0A ( External discharge mode)
• CH2: 0.1-2.0A
Charge Powe
• DC Input: 2 x 200W
• AC Input: Max 200W (CH1 + CH2 = 200W)
• Support power distribution
Discharge Power
• CH1: 6W / 200W (External discharge mode)
• CH2 : 6W
Balance Current: Max.1000mA / cell
Support Battery Types:
• Lipo / LIHV / Life / Lilon (1-6S)
• NIMH / Nicd (1-16s)
• Lead Acid 2V-24V (1-12S)
LCD Screen type: 24'' 320X240 IPS LCD
Dimensions: 100 x 199 x 64mm
Weight: 450g
Item Packing
UltraPower UP7 AC200W DC400W 10A x 2 Dual Channel Balance Charger Discharger x 1
Detailed Images
