Walksnail Avatar HD Goggles L 5.8GHz 4.5Inch HD Display FPV Goggles Support Head Tracker Compatible with Walksnail Digital VTX

Part No.:	WA-Avatar-4.5
Manufacturer:	Feixiang

Send to a friend

Features

*The goggles are equipped with an in-house developed full-stack image transmission head tracking system. The head tracking sensor, employing a nine-axis gyro module, is integrated into the goggles to capture the pilot's head movements. Paired with a gimbal, it sends signals via the image transmission system to control the camera's pan and tilt, providing pilots with a cockpit-like sensation.
*The Avatar HD system adopts industry-leading H.265 encoding technology, delivering 1080P/60FPS FPV video quality for an immersive and responsive experience.
*It also supports PPM signal output to Radio Controllers via the Goggles L's 3.5mm headphone TX connector, which in turn outputs to the drone.
*Employing cutting-edge optical design, the goggles offer distortion-free and high-resolution imaging at 1920X1080, coupled with a 4.5-inch HD display for clarity and eye protection.
*With a built-in Micro SD card slot, users can easily record their flights with just one touch, capturing every exhilarating moment.
*Featuring a high-performance directional antenna with a gain of up to 4.9 dBi, the goggles ensure stable signal transmission, enabling longer flight distances.
*Compatible with 2-6S voltage input, the goggles are compatible with all drone batteries, providing users with greater flexibility.
*The detachable lens design supports various vision needs, allowing for the installation of nearsighted, farsighted, or blue light-blocking lenses to meet individual preferences.
*Compatibility with all current Walksnail VTX models ensures stability and the ability to fly when you want to, in both indoor and outdoor environments.
*The front cover has an added light-up feature with a cool light bar design to add a technological touch to your gear.
*Utilizing premium polyurethane foam, the goggles' face mask ensures softness and comfort, while reducing light leakage for an enhanced wearing experience.
*The Goggles L is suitable for RC cars, FPV drones, and fixed-wing. With the most competitive cost, Goggles L allows you to experience true digital HD FPV visuals, bringing clarity and immersion to your FPV adventures.

Product Details

Model: Avatar HD Goggles L
Communication Frequency: 5.725-5.850GHz
Transmitter Power(EIRP): FCC:<30dBm; CE:<14dBm; SRRC:<20dBm; MIC:<25dBm
I/O Interface: 4Pin 3.5mm Plug, DC5.5*2.1mm, Micro SD Card Slot,
Gyro: Nine-axis gyroscope
Transmission Resolution: 1080p60fps, 720p60fps
Code Rate: Max 50 Mbps
Min. Latency: Average 32ms
Average Gain: 4.9dBi
Polarization: LHCP
Transmission Distance: ＞4km
Channel: 8
Screen Resolution: 1920*1080/60Hz
Screen Material: LCD
Screen Size: 4.5 Inch
Power Input: 6V-25.2V(2S-6S)
SD card: Support 256G
Net weight: 350±10g
System: Avatar HD System
