T21 All in one Handhold FPV Portable Ground Station remote control system for UAV & drone

T21 All in one Handhold FPV Portable Ground Station remote control system for UAV & drone
Part No.: QA-T21
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

T21 is a single-handed ground station with integrated industrial-grade three-proof computer and integrated link remote control system. It can be independently programmed with dual S-BUS design. It has a remote-controlled aircraft, remote-controlled gimbal, real-time flight status feedback, and real-time remote control status Feedback, route planning and other functions. The dual system platform supports most of the ground station software on the market. Industrial-grade computers and military-grade transmission links not only ensure the safety and stability of the aircraft, but also are simple to operate and easy to carry. Widely used in drones, unmanned ships, fire trucks, and detonation robots.

Product Details

Channel: 16CH
Communications Frequency: 900MHz
Effective Distance: 5 ~ 30KM (depending on the environment)
RF Power: 1W (Adjustable)
Remote Control Delay: 40ms
Battery: 3.7V/7500mah
Duration Time: 3 Hours for Full-load
Dimensions: 300 x 160 x 40mm (L*W*H)
Net Weight: about 1000g
Computer System: for Windows 10 and Android 5.1
Display Screen: 8 Inch IPS / 320CCD
Resolution: 1280 x 720
Processor: Intel Cherry Trail Z8350
Memory: 4GB DDR3
Storage Capacity: 64GB
Three protection features: IP67
External Ports: USB, 4G Slot(Unicom 4G), TF card

Receiver:
Size: 53 * 40 * 14mm
Working frequency:  900MHZ optional
Power supply voltage: 7.4 ~ 12V
Working current: 300MA (12V power supply)
Power: 100mV ~ 1W
Antenna: 2dB rod antenna
Weight: 43g
Working temperature: -10 ~ + 50 ℃

Item Packing

Remote control x 1
receiver x 1

Detailed Images
