Happymodel Diamond VTX 5.8G 40ch 25mw-200mw Switchable VTX with DVR

Happymodel Diamond VTX 5.8G 40ch 25mw-200mw Switchable VTX with DVR
Part No.: XP628
Manufacturer: happymodel

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

Short touch the button to Start/Stop Video recorder
The video will split to 2 minutes automatically
Best for upgrade Mobula7 / Eachine Trashcan
Small size , lighter only 3gram and easy to mount in a regular whoop
Built-in DVR(Video size 1280x720)
Auto start when power on
Note: Auto-save when Power off is not support, please remember to press the stop button after landing

Product Details

Brand Name: Happymodel
Output power: 25~200mw switchable
Frequency: 40CH
Input voltage: 3.3V 5.5V
Current consumption: 250mA~510mA(type)
Antenna: RG178 antenna
U.FL interface
Frequency: 5.8GHz 5bands 40 channels
With Raceband
Smartaudio ready
Weight: 3g without antenna
Video Output Size: VGA (640x480)
Video Output format: NTSC
Record video size : 1280x720 @25FPS
TF Card support: Max.32G
Interface: JST SH1.0 3pin for Camera
        JST SH1.0 5pin for Connect with F3/F4 Flight controller
Compress Format: AVI

Recommended parts to fit the Diamond VTX
Happymodel Mobula7 V2 canopy
CADDX EOS2 camera
Runcam Nano2 camera
Test demo  https://www.youtube.com/watch?v=RE0j-ZqID8U&

Item Packing

Diamond_VTX  x1
JST SH1.0 3Pin wire for camera  x 1
JST SH1.0 5Pin wire for flight controller x 1

Detailed Images
