Matek MATEKSYS ELRS-R24-P6 R24-P6 EXPRESSLRS 2.4G 6CH PWM Receiver ExpressLRS 3.0 VBAT Voltage Sense for RC Airplane Fixed-Wing
| Part No.: | ELRS-R24-P6 |
| Manufacturer: | Matek |
Send to a friend
Features
Product Details
Specifications
- ESP8285, SX1281
- Antenna connector: IPEX MHF 1
- 6x PWM outputs
- Support 2~8S VBat voltage sense
- RF Frequency: 2.4GHz (2400~2480MHz)
- Telemetry power: 12dbm
- Receiver output protocol: PWM
- Input voltage: 4~9V DC @ “+” pad
- Voltage sense: 34V Max. @ “VBat” pad
- Power dissipation: 45mA(binding), 85mA(wifi mode)
- PCB size: 20mm x 18mm
- Weight: 2g w/ antenna
Firmwares
- ExpressLRS 3.0 or newer, DIY 2.4 GHz / DIY 2400 RX PWMP EX
- ExpressLRS wiki for PWM receiver, Click HERE
- Make sure Receiver and TX module both are running ExpressLRS 3.0 or newer
——————————————————
- Receiver has ExpressLRS 3.0 preloaded with binding phrase “123456”, the Receiver will never enter binding mode if using the traditional binding procedure.
- You need to reflash it with your binding phrase OR go into WebUI to set your binding phrase.
Flashing via Wifi
- Disconnect ESC and servos from receiver first.
- Power on receiver by 5V source. Receiver’s LED(Red) will blink slow at first, and after 20s, it should blink fast indicating it’s on Wifi Hotspot Mode.
- More detailed steps, pls refer this page.
- Target: DIY 2.4 GHz / DIY 2400 RX PWMP EX
Flashing via UART
1. Disconnect ESC and servos from receiver first.
2. Wire the receiver into the USB-TTL adapter, with TX on receiver connected to the Rx on the USB-TTL, and RX on receiver connected to the Tx of the USB-TTL. Wire 5V and GND of the USB-TTL to 5V and GND of the Receiver.
3. Press the boot button while powering on the receiver, then release – the Red LED on receiver should now be solid.
4. Select the target DIY 2.4 GHz / DIY 2400 RX PWMP EX and “UART” for Flashing Method, set your bind phrase and Firmware Options and once done, click on Build and Flash.
Item Packing
1x IPEX MHF1 Antennas. 15cm
Dupont 2.54 pins (Board is shipped unsoldered)
Detailed Images
