Operating Voltage: 8.4 – 16.8V DC
Standby Current: ≤200mA
Locked Rotor Torque:
At 8.4V: ≥90kg.cm
At 12.0V: ≥130kg.cm
At 16.8V: ≥150kg.cm
Un Load Speed:
At 8.4V: ≤0.19sec/60°
At 12.0V: ≤0.16sec/60°
At 16.8V: ≤0.13sec/60°
Rotating Direction: CCW (500 – 2500us), Counterclockwise rotation, i.e., forward
Pulse Width Range: 500 – 2500u5
Neutral Position: 1500us
Operating Travel Angle: 180 ± 10° (500 – 2500us)
Max. Operating Travel Angle: 358° ± 10° (500 – 2500us)
Mechanical Limit Angle: 360°

Dead Band Width: ≤3us
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -20°C to +60°C
Weight: 365 ± 0.5g
Case Material: CNC AL6061
Gear Set Material: Metal Gear
Reduction Ratio: 1; 257
Motor Type: Brushless Motor
