DJI NAZA-M LITE and GPS COMBO NAZALTCB




DJI NAZA-M LITE and GPS COMBO NAZALTCB
For entry-level enthusiasts, DJI now brings out the most cost-effective solution, the NAZA-M Lite flight control system. As the simplified version of NAZA-M, it inherits the high reliability and stability of NAZA-M. The innovative All-in-one design simplifies installation and saves space and weight. It contains inner damping, controllers, 3-axis gyroscope, 3-axis accelerometer and barometer in its light and small Main Controller. It can measure flying altitude, attitude and therefore can be used for autopilot/automatic control.
The advanced attitude stabilization algorithm not only inherits the outstanding flight stability of DJI products, but also provides excellent maneuverability. It is more flexible and stable, and gives the hobbyists a wonderful flight experience.
It offers three types of control modes: GPS Atti. Mode (with GPS module), Atti. Mode, Manual Mode. The pilot can switch between the three modes to achieve different flight characteristics. It also can adjust automatically within the flight environment and intelligently switch between GPS Atti. Mode and Atti. Mode to make sure the flight is safe and secure. .

| BASIC PERFORMANCE | Supported Multi-rotor | Supported ESC output | Recommended Transmitter | Working Voltage Range |
|---|---|---|---|---|
| Quad-rotor I4, X4 / Hex-rotor I6, X6, IY6, Y6 | 400Hz refresh frequency | PCM or 2.4GHz with minimum 4 channels | MC:4.8V~5.5V VU: 7.2V ~ 26.0 V (recommend 2S ~ 6S LiPo) |
|
| Power Consumption | Operating Temperature | Assistant Software System Requirement | ||
| MAX1. 5W (0.3A@5V) Normal:0.6W (0.12A@5V) |
-10°C ~ 50°C | Windows XP sp3 / Windows 7 / Windows 8 | ||
| FLIGHT PERFORMANCE | Hovering Accuracy (GPS Mode) |
Max Yaw Angular Velocity | Max Tilt Angle | Ascent / Descent |
| Vertical:±0.8m Horizontal:±2.5m |
200°/s | 45° | ±6m/s | |
| HARDWARE | Weight | Dimensions | Built-In Functions | |
| MC:25g VU:20g GPS:21.3g |
MC: 45.5mm x 31.5mm x 18.5mm VU: 32.2mm x 21.1mm x 7.7mm GPS & Compass 46mm(diameter)x9mm |
Three Modes Autopilot Enhanced Fail-safe Low Voltage Protection S-Bus Receiver Support 2-axle Gimbal Support |
-NAZA -m Lite flight control X 1
-GPS X 1
-Power supply module X 1
