Model: FB-2306-C001
Storage temperature range: -40℃～80℃
Operating temperature range: -40℃～60℃
Size: 30.2*14.6*31.5mm
Weight: 42.5g±1g
Gear type: Steel
Limit angle: No limit
Bearing: Ball bearings
Horn gear spline: 25T/4.95mm
Horn type: 0°
Case: Aluminium
Connector wire: 26±1cm
Motor: Brushless motor
Operating voltage range: 6-14V
Idle current (at stopped): 35mA@12V
No load speed: 0.072sec/60°(140RPM)@12V
Running current(at no load): 110mA@12V
Peak stall torque: 6kg.cm@12V
Rated torque: 2kg.cm@12V
Stall current: 1.25A@12V
Command signal: Pulse width modification
Control system type: Digital comparator
Pulse width range: 1000~2000usec
Neutral position: 1500μsec
Running degree: 90° (at 1000→2000μsec)
Dead band width: ≤4μsec
Feedback voltage:
1000us→0.31V
1500us→1.64V
2000us→3.05V
Rotating direction: Clockwise (at 1000→2000μsec)
