Model: FT-1090-C001
Storage temperature range: -30℃～80℃
Operating temperature range: -20℃～60℃
Size: 23.2*12.1*25.25mm
Weight: 10.5±1g
Gear type: POM
Limit angle: No limit
Bearing: NO
Horn gear spline: 20T/3.95mm
Gear ratio: 1/416
Case: PC plastic
Connector wire: 25cm
Motor: Core motor
Operating voltage range: 4V-7.4V
Idle current (at stopped): 6mA@6V
No load speed: 0.1sec/60°@6V
Running current(at no load): 150mA@6V
Peak stall torque: 1.8kg.cm@6V
Rated torque: 0.6kg.cm@6V
Stall current: 1000mA@6V
Command signal: Pulse width modification
Amplifier type: Digital comparator
Pulse width range: 500~2500μsec
Stop position: 1500μsec
Running degree: 280°(at 500→2500μsec)
Dead band width: ≤4μsec
Rotating direction: Counterclockwise (at 1500→2000μsec)
