Model: FT-5930-C001
Storage Temperature Range: -30℃～80℃
Operating Temperature Range: -20℃～60℃
Size: 40.1*20.1*38.9mm
Weight: 61±1g
Gear type: Steel
Limit angle: NO limit
Bearing: Ball bearings
Horn gear spline: 25T/5.9mm
Gear Ratio: 1/300
Case: PA+Fiberglass
Connector wire: 30±1CM
Motor: Coreless Motor
Operating Voltage Range: 4-9V
Idle current (at stopped): 20mA@8.4V
No load speed: 0.1sec/60°(100RPM)@8.4V
Running current(at no load): 320mA@8.4V
Peak stall torque: 39.5kg.cm@8.4V
Rated torque: 13.1kg.cm@8.4V
Stall current: 5.1A@8.4V
Command signal: Pulse width modification
Control System Type: Digital comparator
Pulse width range: 500~2500 μsec
Stop position: 1500 μsec
Running degree: 180°±5°(at 500→2500μsec)
Dead band width: ≤4 μsec
