Model: FT-9020-C001
Storage Temperature Range: -30℃～80℃
Operating Temperature Range: -40℃～60℃
Size: 30*15*37.5mm
Weight: 46.8±2g
Gear Type: Steel
Limit Angle: No limit
Bearing: Ball Bearings
Horn Gear Spline: 25T/5.95mm
Gear Ratio: 1/305
Case: Aluminum
Connector Wire: 26±1cm
Motor: Brushless Motor
Operating Voltage Range: 9V-12V
Idle Current (at Stopped): 36mA@12V
No Load Speed: 0.105sec/60° (95RPM)@12V
Running Current (at No Load): 200mA@12V
Peak Stall Torque: 20kg.cm@12V
Rated Torque: 6.4kg.cm@12V
Stall Current: 400mA@12V
Command Signal: Pulse Width Modification
Amplifier Type: Digital Controller
Pulse Width Range: 500→2500 μsec
Stop Position: 1500 μsec
Running Degree: 200±5°(at 500→2500μsec)
Dead Band Width: ≤4 μsec
Rotating Direction: Counterclockwise (at 500→2500 μsec)
