FLYSKY FGR12B 2.4GHz 12CH Receiver PWM PPM Ibus for AFHDS3 Transmitters PL18/ NB4 /NB4 Lite

SKU FS-FGR12B Category Tag Brand:

FLYSKY FGR12B 2.4GHz 12CH Receiver PWM PPM Ibus for AFHDS3 Transmitters PL18/ NB4 /NB4 Lite

Dear customer:

Welcome to our FeiXiang website. We sincerely invite you to join our exclusive membership and become our member. You will be able to enjoy our membership price and more services!

Register login

The FGr12B receiver adopts Flysky’s third-generation automatic frequency hopping digital system (AFHDS 3).It uses a single-antenna bidirectional transmission system and output PWM/PPM/ i-bus in signals. It supports all AFHDS3 transmitter and RF modules.

Product Model: FGr12B
Adaptive transmitter: all transmitter supporting AFHDS3 (PL18, NB4,
NB4 Lite, etc.)
Model Type: Car/Boat ect.
PWM Channels: 11（Version 2.0 will be upgraded to 12channels)）
RF: 2.4GHz
2.4G Protocol: AFHDS 3
Antenna: Single Antenna
Input Power: 3.5-9V
Data Output: PWM\PPM\i-bus in
Temperature Range: -10℃—+60℃
Humidity Limit: 20%-95%
Online Update: Yes
Dimensions: 37*25*17.5mm
Weight: 11.2g
Certification: CE，FCC ID:N4ZFGR12B

1 x FGr12B Receiver
