Imaging Device: 1/3″ Sony 960H Exview HAD CCD II – PAL
Horizontal Resolution：700TVL
Effective Pixels: PAL: 976H×582V
Scanner System: PAL
Minimum Illumination: 0.01LUX/F1.2
D/N Selection： Color/B/W/Auto
O.S.D Menu： Available
Language: Chinese/English
Noise Reduction： 2D-NR 0-15 level
Gain Control: Auto/MANUAL
White Balance: Auto/MANUAL
Backlight Compensation: BLC/HLC/OFF selectable
S/N Ratio: ≥48dB
Electronic Shutter: PAL:1/50-1/100.000s;
Sync. System: Internal
Video Output: 1.0Vp-p/75Ω
Lens: 3.6mm
Power: DC12V±5%
working current: 70mA
Operation Tem: -20℃–60℃

Wiring guide:
Red- positive (“+”),
black – Negative (“-“),
Yellow – signal
