Futaba HPS-HC701 Brushless HV Low Profile Cyclic Servo High Performance for RC Helicopters 500-800 3D F3C
Futaba HPS-HC701 Brushless HV Low Profile Cyclic Servo High Performance for RC Helicopters 500-800 3D F3C
The HPBLS Series Servos achieve high torque and low power consumption. The HPS Servos not only ensure high centering accuracy and large torque, but also offer good balance among speed, torque, and power consumption.
Feature:
Suitable for RC helicopters 500-800 3D/F3C
Programmable/HV Brushless Servo.
Supports 760uS (Factory Default, able to be set to 1520uS w/ GPB-1 v4.3 .)
Programmable and compatible with S.Bus and S.Bus2 systems.
Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
Upper/middle/bottom: Aluminum Case
Model: HPS HC701
1520µs
Speed: 0.07sec/60°(7.4V) / 0.08sec/60°(6.6V)
Torque: 30.0kgf・cm(7.4V) / 26.5kgf・cm(6.6V)
Torque: 416.6ozf・in(7.4V) / 368.0ozf・in(6.6V)
760µs
Speed: 0.07sec/60°(7.4V) / 0.08sec/60°(6.6V)
Torque: 27.0kgf・cm(7.4V) / 24.0kgf・cm(6.6V)
Torque: 375.0ozf・in(7.4V) / 333.3ozf・in(6.6V)
Dimensions: 40.5×21.0×26.2mm / 1.59×0.83×1.03in
Weight: 54g
Rated Voltage: DC 6.0V-7.4V
Operating Voltage: DC 4.8-8.4V
HPS HC701 Servo x1
