Hitec 35485S HS-5485HB Standard Karbonite Gear Digital Top BB Servo
This is a Hitec Programmable Standard Digital Servo with Hitec “S” Type Connector.
FEATURES:
Four heavy duty Karbonite gears Top ball bearing Programmable Digital Designed for .20-.60 Airplanes, Steering & Throttle Servo, and Trucks and Boats
YOU WILL RECEIVE:
One servo with pre-installed round (disk) servo horn Four grommets Four brass eyelets Four round, flanged, phillips head screws 1.5 x 14mm One adjustable servo horn One large X servo horn 1.7″ (43mm) end to end One small X servo horn 1.2″ (30mm) end to end One straight servo horn 1.3″ (33mm) end to end
SPECIFICATIONS:
Speed: 0.20sec/60 degrees at 4.8V Torque: 5.2 kg-cm (72 oz-in) at 4.8V Length: 39.8mm (1.57″) Width: 19.8mm (0.78″)
– Motor Type: 3 Pole
– Bearing Type: Top Ball Bearing
– Speed (4.8V/6.0V): 0.20 / 0.17
– Torque oz./in. (4.8V/6.0V): 72 / 89, Torque kg./cm. (4.8V/6.0V): 5.2 / 6.4
– Size in Inches: 1.57 x 0.78 x 1.49, Size in Millimeters: 39.88 x 19.81 x 37.85, Weight ounces: 1.59, Weight grams: 45.08
– Product Dimensions: 1.6 x 0.8 x 1.5 inches ; 4.8 ounces
HS-5485HB Servo x1
