The HS-5245MG is a mini powerhouse. Although it weighs in at a paultry 1.12 oz, this servo puts out 76 oz-in. of torque while still maintaining a quick .12 sec. to 60°. If a standard size servo will not fit and you still need more power, the HS-5245MG should work just great and being digital allows you to program just about all the functions of the servo if needed. We offer this servo in several configurations, 90° stock rotation, 180° modified rotation, continuous rotation (potentiometer is left outside the servo case) and reverse rotation.
Control System: +Pulse Width Control 1500usec Neutral
Required Pulse: 3-5 Volt Peak to Peak Square Wave
Operating Voltage: 4.8-6.0 Volts
Operating Temperature Range: -20 to +60 Degree C
Operating Speed (4.8V): 0.15sec/60° at no load
Operating Speed (6.0V): 0.12sec/60° at no load
Stall Torque (4.8V): 61 oz/in. (4.4kg.cm)
Stall Torque (6.0V): 76 oz/in. (5.5kg.cm)
Operating Angle: 45 Deg. one side pulse traveling 450usec
360 Modifiable: Yes
Direction: Clockwise/Pulse Traveling 1500 to 1900usec
Current Drain (4.8V): 3mA/idle and 180mA no load operating
Current Drain (6.0V): 3mA/idle and 230mA no load operating
Dead Band Width: 1usec
Motor Type: 3 Pole Ferrite
Potentiometer Drive: Direct Drive
Bearing Type: Dual Ball Bearing
Gear Type: 4 Metal Gears, 1 Resin Gear
Connector Wire Length: 11.81″ (300mm)
Dimensions: 1.3″ x 0.7″x 1.2″ (32 x 17 x 31mm)
Weight: 1.12oz (32g)
Hitec 5245MG Servo x1
Related products
-
Hitec Servo
Hitec HSR-5980SG Digital Robot Servo
-
EMAX Servo
EMAX ES3003 17g/ 3.5kg/ .13 sec Analog Servo
-
Feetech Servo
