Hobbywing EzRun MAX10 G2 80A Sensored Brushless ESC Waterproof Speed Controller for 1/10th On-road/Off-road Short Course Truck
Hobbywing EzRun MAX10 G2 80A Sensored Brushless ESC Waterproof Speed Controller for 1/10th On-road/Off-road Short Course Truck
Upgraded sensor mode, great throttle response
Smart technology increases heat dissipation effectiveness
Large capacitor built-in, double explosion-proof
Smart freewheeling technology, higher efficiency
Data logging, convenient
IP67 protection, all-weather operational
Product Name: EZRUN MAX10 G2-80A
Product Number: 30102604
Type
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Waterproof: Waterproof
Specifications
Cont./Peak Current: 80A/520A
Input Voltage: 2-3S Lipo
BEC Output: 6/7.4V,5A
Wires & Connectors
Input Wires: Red-12AWG-150mm*1 Black-12AWG-150mm*1
Input Connectors: XT60
Output Connectors: 4.0mm Gold (female)
Fan
Size: 25x25x10mm
Output Wires: 5-7.4V
Input Connectors: Powered by BEC
ESC Programing via
SET Button on ESC: No
LED Program Box: Supported
LCD Program Box: Supporte(G2)
OTA Programmer: Supported
Programming Port: Separate
Firmware Upgrade: Supported
Size & Weight
Size: 53mm*39.5mm*37.2mm
Weight: 120g(w/Wires)
Applications
Applications: SL BL Motors / SD BL Motors
Vehicles: 1/10th On-road/Off-road Short Course Truck(Light-duty)
KV Rating/T Count: With 2S Lipo: KV≤ 6000; With 3S Lipo: KV≤ 4200 3652 size motor
MAX10 G2 80A Sensored Brushless ESC x1
