iFlight ipower GM6208 brushless gimbal motor with AS5048A, applicable to single-lens reflex (SLR) gimbal aerial photography.
iFlight ipower GM6208 brushless gimbal motor with AS5048A, applicable to single-lens reflex (SLR) gimbal aerial photography.
The GM62 series motor by iPower Motors is the ultimate brushless gimbal motor for DSLR / CANON 5D MARKII, MARKIII Cameras. This motor is designed for large scale multi-rotor platforms looking to lift Red Epic & DSLR sized gear – 4KG/cm Torque.
Model: GM6208
Motor Out Diameter: Ф69.5±0.05mm
Configuration: 24N/28P
Motor Height: 32±0.2mm (Included with Encoder housing)
Hollow Shaft(OD): Ф25-0.01/-0.015 mm
Hollow Shaft(ID): Ф22+0.05/+0 mm
Wire Length: 610±3mm
Cable AWG: #24
Motor Weight: 265±0.5g
Wire plug: 2.5mm dupont connector
No-load current: 0.08±0.1 A
No-load volts: 20 V
No-load Rpm: 209~231 RPM
Load current: 1.2A
Load volts: 20V
Load torque(g·cm): 2600-3600
Motor internal resistance: 32Ω±5%（Resistance varies with temperature）
High voltage test: DC500V 1mA @2sec
Rotor housing runout: ≤0.1mm
Steering (axle extension): clockwise
High-low temperature test:
High temperature: Keep at 60℃ for 100 hours, and the motor can work normally after 24 hours at room temperature
Low temperature: Keep at -20℃ for 100 hours, and the motor can work normally after 24 hours at room temperature
Maximum power: ≤25W
Working current: 3-5S
Working temperature: -20~60℃;10~90%RH
1 x GM6208 150T Brushless Gimbal Motor
1 x AS5048A Encoder with aluminum case
