iFlight SucceX-D Whoop F4 20A ESC AIO Board (MPU6000) integrated flight control for DJI HD FPV system
iFlight SucceX-D Whoop F4 20A ESC AIO Board (MPU6000) integrated flight control for DJI HD FPV system
SucceX-D Whoop F4 AIO Board (MPU6000)
Top Features:
• DJI Plug-and-Play – No need to solder tiny wires!
• BEC output：5V 2A/10V 2A
SucceX-D Whoop F4 AIO
Size：30.5*30.5mm
Mounting pattern：25.5*25.5mm/φ3mm
Connector：Micro-USB
MCU：STM32F411
Gyro：MPU6000
Blackbox：8MB
BEC output：5V 2A/10V 2A
INA pad：n uart2
Barometer：no
Constant current：20A，25A（Burst）
Input：2-5S（8-25V）
Current sensor：yes
BLHeli：BLHeli-S
Telemetry：no
FC Firmware：IFLIGHT_F411_PRO
Target：STM32F411
Config：IFLIGHT_F411_PRO.config
ESC Firmware：G-H-30 BLS 16.7
SucceX-D Whoop F4 AIO Board x 1
Capacitor 470uF/16V x 1
XT30 18awg cable
Wire harness (plug&play) for DJI Air Unit x 1
M2 silicon grommets x 4
M2 damping balls x 4
M2*8mm Screws x 4
