ISDT X16 1100Wx2 20Ax2 Dual Channel AC/DC 16S Smart Battery Charger for 2-16S Life/LiPo/LiHv/ULiHv Battery Balance Charger
ISDT X16 1100Wx2 20Ax2 Dual Channel AC/DC 16S Smart Battery Charger for 2-16S Life/LiPo/LiHv/ULiHv Battery Balance Charger
– All-round, continuous high-energy.
– Support 2~16S LiFe, LiPo, LiHv, ULiHv battery, The ultra-high voltage lithium battery with 4.45V battery cell voltage is no problem.
– High Power Synchronous Dual Channel, with Smart Charging.
– Smart High Speed Processor delivers parameter interfere to each port.
– Supports Bluetooth Connect Functionand Mobile Operations.
– Built-in independent dual 1100W ×2(@220V AC) high-power AC power supply, With short circuit protection, overload protection, under voltage protection, over voltage protection, over temperature protection, Support AC 120V & AC 220V voltage input.
– Two channels work independently and stably, which can be independent or combined.
– Provide a steady stream of power for X16 stability.
Input voltage: AC 100~240V
Output voltage: DC 10~72V
Charging current: 1.0~20.0A ×2
Discharging current: 0.5~3.0A ×2
Max. charging power: 1100W ×2(@220V AC)
800W x2(@110V AC)
Max. discharging power: 50W ×2
Balance current: 1.5A/Cell
Supported battery types and cell count: LiFe，LiPo，LiHv，ULiHv (2~16S)
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Working temperature: 0℃~40℃
Storage temperature: -20℃~60℃
Dimension: 276×246×82mm
Weight: About 3.5kg
ISDT X16 Charger x1
