MAD 7005 EEE 115KV 230KV Brushless Motor Ultra-Lightweight Power for Fixed-Wing UAVs Long Range
MAD 7005 EEE 115KV 230KV Brushless Motor Ultra-Lightweight Power for Fixed-Wing UAVs Long Range
7005 Motor – Redefining Industrial Drone Performance with Ultra-Lightweight Power
188g , 6kg Burst Thrust – The Perfect Balance of Efficiency and Power
“1.5kg Continuous Thrust at Peak Efficiency – 30% Longer Flight Time, Zero Power Anxiety”
Optimized for mapping/logistics drones | Industry-leading 14.3g/W efficiency with 24″ props
“6kg Instant Thrust – Your Emergency Lifesaver”
Critical overload protection for sudden payload shifts or emergency climbs
“188g Ultra-Lightweight – Revolutionizing Payload Capacity”
12% lighter than comparable 6kg-thrust motors | More weight allowance for critical payloads
“Industrial-Grade Precision Compatibility”
Seamless 40-60A ESC pairing | Full 22-26″ prop flexibility
Unlock 7005’s golden efficiency zone today – Where every gram and every watt creates maximum value!
Model: MAD 7005 EEE
Number of pole pairs: 14
Stator: Anticorrosive
Varnished wire Degree: 180°C
Motor Size: D:79×21.8 mm
Magnet Degree: 150°C
Degree of Protection: Rain protection
Cable Length: 80 mm # Awg(Black) silicone
Centrifugal Heat Dissipation: Independent
Rotor Balance: ≤5 mg
Propeller Mounting Holes: D:20 M3×4, D:23 M4×4
Motor Balance: ≤10 mg
Shaft Diameter: IN: 15 mm
Motor Mounting Holes: D:32 M4×4
Bearing: EZO 6802ZZ*2
Disruptive test: 500V
7005 EEE motor x1
