This product is a bidirectional power amplifier, specially developed in 2.4 GHz band, which meets the standard of 802.11b/g/n. The product matches direct sequence (DSSS), orthogonal frequency division multiplexing (OFDM) and other frequency expansion technologies. By using Time Division Duplex(TDD) fast microwave detection technology and linear power amplifier technology, the radio frequency communication distance can be greatly extended while the transmission rate of 802.11b/g/n wireless equipment is constant.

– Lightweight, mini size, advanced circuits ensure a fast and stable signal transmission and receiving.
– 13dB transmitting gain can enhance the transmission power by 20 times and increase the transmission distance.
– 4000mW of transmit power can greatly expand radio coverage area.
– 2.5dB noise figure, it can improve the product receiving sensitivity, greatly expand the receiving distance.
– Can expand any 2.4G frequency band, suitable for the TDD work mode product.
– Plug and play, no need others software setup.
– All metal shell, good heat dissipation.
