Display size: 3.95” TFT LCD (480×320)
Max low input frequency: 800MHz, 6GHz in Ultra mode
Resolution filters in 1,3,10 steps: from 200Hz to 850kHz
Max output frequency: Sinus up to 800MHz, Square wave up to 4.4GHz
output level: -104dBm to -16dBm
Ultra mode: Level calibrated up to 5.3GHz
Internal LNA gain: 20dB up to 4GHz
Displayed points per scan: max 450

0-350MHz scan time: 165ms
Shortest zero span time: 17ms
DANL at 100MHz: -153dBm/Hz (LNA Off) / -169dBm/Hz (LNA On)
DANL degrading in ultra mode: 10dB above 2.5GHz, 25dB above 5.3GHz
Phase noise at 10kHz offset: -92dBc/Hz
Phase noise at 100kHz offset: -110dBc/Hz
Input 1dB compression level: +0.5dBm (LNA Off) / -26.5dBm (LNA On)
IIP3 without LNA: +18dBm (at least 2MHz apart) / 0dBm (500Hz apart)
IIP3 with LNA: -8dBm (at least 2MHz apart)
Frequency stability: <1ppm (-10°C ~ +55°C)
SD card slot: micro SD card
Audio out: 3.5mm headphone plug
FW update mode activation: Push jog button before switch on
Maximum current consumption: 330mA
Maximum charging current: 1300mA
Battery: Li-polymer 3.7V 3000mAh
RF connectors: SMA female
Communication Interface: USB-CDC(Type-C), UART-TTL(2.54mm Connector)
