Radiolink AT9S Pro 2.4G 12CH DSSS FHSS Transmitter with R9DS Receiver Compatible TBS Crossfire Module for RC Drone
Radiolink AT9S Pro 2.4G 12CH DSSS FHSS Transmitter with R9DS Receiver Compatible TBS Crossfire Module for RC Drone
AT9S Pro 10CH/12CH
Includes 10 Channel Receiver
Full Featured 2.4GHz Premium Transmitter
Optional DSSS&FHSS/CRSF Protocols
Compatible with TBS Crossfire TX
Ideal for Flying Virtually any Type of Aircraft
Designed for the Experts, easy Enough for Beginners
User-Friendly Design for Ease of Operation and Handling
Excellent Transmitter for Recreation, Sport, Competition or 3D Flying
Compatible with SBUS, PPM, PWM and CRSF
With DSSS&FHSS protocol, SBUS, PPM and PWM can operate simultaneously for seamless user control
With CRSF protocol, TBS Crossfire TX is needed to bind to BLACKSHEEP receiver
Transmitter is fully compatible with RadioLink’s R6DSM, R6DS, R9DS*(Std), R12DSM and R12DS receivers
Compatible receivers cover a wide range of aircraft to meet customers’ most demanding applications
Frequencies Band: 2.4GHz ISM band（2400MHz~2483.5MHz）
Bandwidth: 5.0MHz
ACPR: >38dbm
Operating Current: DSSS&FHSS < 90mA@12V
CRSF Depends on the transmission power selected
Operating Voltage: 7.4～18.0V
Control Range: DSSS&FHSS – 4000m（2.49 Miles) in the air (Maximum range is tested in an unobstructed area free of interference)
CRSF – Depends on the RX and TX from BLACKSHEEP
Channel Quantity: 10/12 (CH5 through CH10/CH12 can be programmed)
Signal Output: PWM/SBUS/PPM/CRSF
Storage Model Quantity: 15
Simulator Mode: Yes with radio frequency off to save battery power
Compatible receivers: 12CH – R12DSM, R12DS / 10CH- R9DS(Std), R6DS, R6DSM / CRSF- Receivers from BLACKSHEEP
Adaptable Models: Rotary Wing/ Fixed-wing/ Glider/ Multirotor/ Car/ Boat/ Robot
AT9S Pro Transmitter x 1
R9DS Receiver x 1
Throttle-Stick Parts x 1
Lanyard x 1
Cable x 1
Manual x 1
Box x 1
