Sunnysky E-R2205 2300KV Brushless Motor 3-4S CW For RC Drone FPV Racing Multi Rotor Quadcopter Red
Sunnysky E-R2205 2300KV Brushless Motor 3-4S CW For RC Drone FPV Racing Multi Rotor Quadcopter Red
Sunnysky E-R2205 2300KV Brushless Motor 3-4S CW For RC Drone FPV Racing Multi Rotor Quadcopter Red
Motor Model / KV：E-R2205/ KV2300
Stator/Rotor Poles：12N14P
Internal resistance：53mΩ
Motor size：φ27.4*31.5mm
Shaft diameter：8.0mm
AWG：20AWG 120mm
Motor weight(wire included)：30.5g
Motor weight(wire excluded)：No data
Rated operational voltage：3-4S
No-load current：1.45A/10V
Maximum continuous power：670W
Maximum continuous current：40A/10s
ESC recommended use：30-45A
Propeller size recommended use：GF5045*3/GF5040*3
E-R2205 2300KV Brushless Motor x 1set
