Motor Model / KV: X2302-V3/ KV1500
Stator/Rotor Poles: 12N14P
Internal resistance: 357mΩ
Motor size: φ28.0*20.5mm
Shaft diameter: 3.0mm
AWG: 20AWG 50mm
Motor weight(wire included): 15.7g
Motor weight(wire excluded): No data
Rated operational voltage: 2-3S
No-load current: 0.3A/10V
Maximum continuous power: 80W
Maximum continuous current: 9.5A/30s
ESC recommended use: 10A
Propeller size recommended use: GWS8043/GWS8060/GWS9050
