SUNNYSKY X4130-III 520KV Brushless Motor for RC Quadcopter Airplanes Fixed Wing Plane
1. Waterproof and dustproof, suitable for all-weather racing.
2. Especially suitable for remote control cars with excellent starting, acceleration and linear functions.
3. Compatible with sensorless and brushless motors, with strong DC capability and excellent heat dissipation.
Motor model / KV value: X4130-Ⅲ/ KV520
Number of slot poles: 12N14P
Phase to phase internal resistance: 12.9m Ω
Motor size: φ 49.7*80.0mm
Shaft diameter : 6.0mm
Motor silicone wire specification: 20AWG 110mm
Motor weight (including wire): 399g
Rated working voltage (lipo): 6S
No load current: 2.5A/10V
Maximum continuous power: 3000W
Maximum continuous current: 120A / 30S
Recommended electric regulator: 120A
Recommended propeller specification: 6S(EOLO15*8/16*8)
X4130-III 520KV Brushless Motor x 1
