ZYX flamingo smart tracking 3-aix gimbal -PRO ZYX02


ZYX flamingo smart tracking 3-aix gimbal -PRO ZYX02
– Can carry 350-1900g of non-reverse camera, or other imaging equipment
– 3axis 360-degree rotation unlimited
– Use 26,500 lithium battery life up to 12 hours
– Equipped with Smart tracking module( M version do not include)
– ZYX new generation motor, stable starting voltage, small size, large torque, low noise, long life, high efficiency, precision
– Equipped with camera quick plate for quick installation and adjustment of camera position
– Adjust the balance with the thumbscrew
– Using ZYX’s highly optimized dedicated EKF attitude fusion algorithm, combined with an efficient motor vector control technique, allows the stabilizer to still obtain stable images in an instant violent movement.
– Efficient MCU solution enables PTZ attitude control frequency up to 8000Hz, ensuring that Flamingo can run faster, more stable and more balanced
– The display is integrated in the control panel for easier operation
– Reserved bottom of the fuselage common threaded bore 1/4
Body weight: 950g
Load Weight:350-1900g
Working Voltage:6.8-12.6V(Standard:8.4V)
Working Current:80mA (Min) 110mA (Standard)600mA(Max)
Working Temperature:-10℃-45℃(Standard:25℃)
Working time:12h-18h
Charging time:3h

Flamingo pro stabilizer x 1
Battery case x 1
Lens holder bracket x 1
Lens fixed screw x 1
Camera fixed screw x 1
26500 Lipo battery x 2
26500 Lipo charger x 1
Usb bata cables x 1
