Noise performance, achieved through proprietary amplifier and filter design techniques.
Integrated shielding significantly reduces capacitive coupling of current conductors affected by high dV/dt signals, and prevents offset drift on the high side in high-voltage applications.
Improvement of total output gain and offset error, trimmed over temperature.
Small size, with the ability for easy installation.
High-reliability monolithic Hall IC.
Low power consumption: 100μΩ internal conductor resistance.
Isolation allows the use of economical, high-side current sensing in high-voltage systems.
3 to 5.5 V single-supply operation.
120kHz typical bandwidth.
3μs output rise time in response to step input current.
Output voltage proportional to AC or DC current.
Factory-trimmed.
Stable output offset voltage.
Near-zero hysteresis.
