Benewake IP67 100m Distance Lidar TF03-100 Vehicle Anti-collision UAV Fixed Height Industrial Security Lidar UART
Benewake IP67 100m Distance Lidar TF03-100 Vehicle Anti-collision UAV Fixed Height Industrial Security Lidar UART
TF03-100 is a industrial high-speed LiDAR with a range of up to 100m. TF03-100 includes compensation algorithms for outdoor glare and other interference, so it works normally under strong light environment and rain, fog and snow conditions①. Different built-in operating modes let customers change parameters and configuration to meet their need.
Product performance
– Operating range：0.1m-100m@90% reflectivity；0.1m-40m@10% reflectivity；0.1m-80m@90% reflectivity&100Klux；0.1m-30m@10% reflectivity&100Klux
– Accuracy：±10cm (within 10m), 1% (10m and further)
– Distance resolution：1cm
– Frame rate：1Hz~1000Hz adjustable (default 100Hz)
– Ambient light immunity：100Klux
– Operation temperature：-25~60℃
– Enclose rating：IP67
Optical parameters
– Light source：LD
– Central wavelength：905nm
– Photobiological safety：CLASS1(EN60825)
– FOV：0.5°
Electrical parameters
– Supply voltage：5V
– Average current：≤180mA
– Power consumption：≤0.9W
– Communication level：LVTTL(3.3V)
– Communication interface：UART/CAN/IO
Benewake IP67 100m Distance Lidar x 1
