Model: FT-325B-C001
Storage Temperature Range: -40℃～80℃
Operating Temperature Range: -20℃～60℃
Size: 64*32.8*90mm
Weight: 490±5g
Gear Type: Steel
Limit Angle: No Limit
Bearing: Ball Bearings
Horn Gear Spline: 25T
Gear Ratio: 1/290
Case: Aluminum
Connector Wire: 430±10mm
Motor: Brushless Motor
Operating Voltage Range: 16V-25V
Idle Current (At Stopped): 20mA@24V
No Load Speed: 0.29sec/60°(34RPM)@24V
Running Current (At No Load): 260mA@24V
Peak Stall Torque: 325kg.cm@24V
Rated Torque: 108kg.cm@24V
Stall Current: 10.2A@24V
Command Signal: Pulse Width Modulation
Control System Type: Digital Comparator
Pulse Width Range: 500~2500μsec
Stop Position: 1500μsec
Running Degree: 180±2°(at 500→2500μsec)
Dead Band Width: ≤4μsec
Running Degree: 180±2°(at 500→2500μsec)
Dead Band Width: ≤4μsec
