Chip: M10(10th Generation Chip)
Frequency: GPS L1，GLONASS L1，BDS B1，GALILEO， ESBAS L1，QZSS L1
Input Voltage: 5V
Antenna: Ceramic Antenna
Channel: 72
Battery: Bilid-in
Compass: QMC5883
Compass Orientation: Plug facing direction of flight and obviously antenna up, BF: CW 90° Flip
Baud Rate: 115200bps
Protocol: Dual NMEA/UBLOX
Output Frequency: 1Hz-10Hz,10Hz default
Speed Accuracy: 0.05m/s
Horizontal Positioning Accuracy: 2D ACC1.5m(outdoor)
Receiver Sensitivity: Trace -166dBm; Capture -160dBm
Dynamic Characteristics: Height 50000m; Speed 500m/s; Acceleration 4G
Operating Temperature: -40C-+85C
Storage temperature: -40C-+105C
Weight: 12g
Size: 25*25*8mm
